Distributed Microgrids: Organising Generation, Storage and Loads into a Controllable System
When PV, storage and loads are spread across multiple owners and connection points in a park, a single centralised point of interconnection cannot optimise local consumption and fault isolation at once. VGRID POWER combines grid-forming PCS, STS transfer modules and hierarchical EMS dispatch into a distributed microgrid with zonal autonomy, grid-connected operation and islanding recovery.
Key Points
- Zonal autonomy: each node runs a grid-forming PCS with local EMS logic, holding voltage and frequency and supplying critical loads even if communications fail.
- Hierarchical coordination: site-level EMS handles economic dispatch while node controllers manage SOC balancing, diesel start/stop and demand response.
- Fault isolation: STS/PCM modules and zoned protection settings keep a single fault local, so other areas continue operating during maintenance.
- Phased expansion: new PV, storage or charging loads connect locally without rebuilding the main distribution board or existing protection scheme.
Selection & Implementation
Design must verify short-circuit capacity, earthing, fault-current levels and communications topology node by node rather than applying one protection setting across the site. VGRID POWER supplies single-line diagrams, node controller configuration tables, on/off-grid transfer logic and commissioning test plans, and validates arbitrage and demand-charge savings against the park’s real load profile.
Frequently Asked Questions
Can off-grid capability be added later?
It depends on whether the installed equipment supports grid-forming operation. Standard grid-tied PCS units cannot establish voltage and frequency on their own; adding an STS/PCM module on the AC bus and a grid-forming PCS is usually required. Reserving the interface at design stage is recommended.
What matters when paralleling multiple units?
Align firmware versions, droop and current-sharing parameters, DC voltage windows and protection settings, then commission under load. Above single-unit capacity, use N+1 redundancy and recheck short-circuit capacity and cable ampacity.
What information is needed for an accurate proposal?
Provide a load schedule with 15-minute load data, daily energy use, required autonomy days, PV and diesel capacity, battery chemistry, local grid code and ingress-protection requirements. We return a single-line diagram, bill of materials and acceptance test plan.
